30/60 Drafting Set Square With Ink Edge
A 30/60/90 drafting set square, 138.6 x 80 mm on the legs with a 160 mm hypotenuse and 3 mm thick. It has a 45° undercut inking edge so pen ink doesn't wick under it, 5 mm tick grooves along both legs, a row of 3/4/5/6/8/10 mm circle-template holes, and a centre lift-out window. Use it for sketching layouts, wiring diagrams and project plans on the desk.
