Pi 4 Edge-On DIN Rail Snap Mount
This mount holds a Raspberry Pi 4B or 3B+ edge-on to a standard 35 mm TH35-7.5 DIN rail (1 mm flanges). The board sits on four M2.5 standoffs on the 58 x 49 mm hole pattern and stands at right angles to the rail, so it takes up roughly 25 mm of rail instead of 85 mm. On the 92 x 87 mm plate, a fixed hook grips one rail flange, a flexure latch snaps over the other, and you release it by twisting a flat screwdriver in the slot.
electronics raspberry-pi din-rail enclosure
⚠ Flagged: mains electrical wiring. Not for safety-critical use without independent engineering review.
