Drafting Board M5 Clamp-On Pencil Ledge
A clamp-on pencil ledge, 80 mm long, for the bottom edge of a tilted drafting board, art desk or homemade slant board. It fits boards 3–26 mm thick and holds two rows of pencils, pens and markers in a 16 mm trough, so they stop rolling onto the floor. Two M5 screws go through 5.5 mm clearance holes and thread into captured M5 nuts (8 mm across flats), and the screws clamp the board against the trough wall. You don't drill the board at all, and you can fit several ledges side by side along a long edge.
