MX Switch Lube Station 20-Well
A 104 x 104 x 8 mm bench block for lubing Cherry MX-style keyboard switches. It has twenty 14.3 mm square wells, each 5 mm deep (the MX plate cutout is 14 mm), so the bottom housings sit level while you brush them. Under each well is a 12.5 mm through-relief that clears the centre post and the plate/PCB pins, and lets you push a housing out from below. Two troughs along the front edge hold springs and stems while you work through a 70- or 90-switch board.
