Pi 4 Wall Box With 1/2 in EMT Entry
A wall-mount Raspberry Pi 4B/3B+ enclosure, 105 x 75 x 32 mm. Its end sleeve takes 1/2 in EMT conduit (17.9 mm OD, 18.3 mm bore, 19 mm deep against a stop shoulder) and an M4 set-screw clamps the conduit, so cable runs to a garage or shed controller can stay in conduit. The Pi sits on four 6 mm standoffs on the 58 x 49 mm pattern, fixed with M2.5 screws from underneath in recessed counterbores. There are open slots for the USB/Ethernet end and the USB-C/HDMI side, four M3 heat-set corner bosses for a flat lid, and four 4.8 mm ears for #8 wood screws.
