ESP32-CAM Window-Port Outdoor Enclosure
A 46 x 62 x 30 mm weatherproof box for an ESP32-CAM. It has a 4 mm front wall that works as a lens hood, a 14 x 22 mm lens slot, and a 24 x 32 x 1.6 mm recess for an acrylic window sealed in with silicone. There is a 6.5 mm hole for the power cable, and four M3 heat-set bosses (35 x 51 mm pattern) for a flat back cover. Two angled ears take #8 (4.2 mm) wood screws, so you can mount it flush under an eave or against a wall without a separate plate.
