GNSS Puck Ground-Plane 8 mm Mast Mount
An 80 mm disc that holds a GPS/GNSS module flat and up off your chassis on an 8 mm steel rod or carbon tube. The face is flat so you can stick copper tape on it as a ground plane. Strap slots in both directions take a hook-and-loop strap or a zip tie around square modules (the 22.6 mm spacing fits about 20–40 mm wide), and a 30 mm socket with ribs grips the mast with an M3 grub screw in a brass heat-set insert.
Ordering a print of any gallery model is free once you're signed in. Want the OBJ for your own printer? Download it for $1 — no account needed, we email you the link. Signed-in members can pay with credits instead.
