22 mm Three-Button Control Station Box
A 140 x 54 x 52 mm open-back control station that holds three standard 22 mm push buttons or selector switches at 40 mm spacing. Each hole has an anti-rotation key notch, the end wall takes an M20 cable gland, and four M4 mounting ears with counterbored 45° gussets let you screw the open back flat to a wall, bench or machine panel.
Flagged: mains electrical wiring. Not for safety-critical use without independent engineering review.
